Comparing Quantization Formats in Image Generation AI Models

A quick look at results from BF16, FP8, and NF4 quantization formats.

Introduction

In this mini blog, we explore how different quantization formats—BF16, FP8, and NF4—affect the output of image generation AI models. These numerical formats determine how data is represented and processed, balancing precision, efficiency, and memory usage.

BF16: High Precision, Moderate Efficiency

BF16 (16-bit floating-point, Bfloat16 or Brain Float16, named because it was developed and used at Google Brain) is a 16-bit floating-point format that retains a wide range of values while reducing memory footprint compared to full 32-bit floats.
It’s widely used in deep learning for its balance of precision and performance. Bfloat16 is a custom 16-bit floating point representation that comprises one sign bit, eight exponent bits, and seven mantissa bits. The IEEE FP32 format uses 32 bits and the IEEE FP16 format uses 16 bits.
Bfloat16 is a truncated version of the IEEE FP32 format, and uses the same number of exponent bits as FP32.
This enables a wider range of real numbers to be represented by BF16, compared to FP16, but with a lot less precision as it has fewer bits to represent data that is after that decimal point in the floating point number. Bfloat16 is used in deep learning frameworks because it has the same range as FP32 (but with less precision after the decimal place), but with fewer bits.

FP8: Compact and Fast

FP8 (8-bit floating-point) takes efficiency further by halving the memory usage of BF16.
This compact format accelerates computation and reduces power consumption and memory use, though it sacrifices some precision, which may impact fine details in generated output.

NF4: Optimized for Neural Networks

NF4 (4-bit Normal Float) is a highly specialized format designed for neural networks, offering extreme efficiency by using just 4 bits per value. It was introduced as a part of the QLora paper here: https://arxiv.org/abs/2305.14314
While it excels in minimizing memory and compute costs, it requires careful optimization to maintain output quality, especially in complex image generation tasks.

Visual Comparison, Spot the difference

Image-BF16 Image generated using the original Flux model, with BF16 precision
Image with BF16 Quantization Model
Image-FP8 Image generated using a modified Flux model, with FP8 precision
Image with FP8 Quantization Model
Image-NF4 Image generated using the latest Flux model, with NF4 precision
Image with NF4 Quantization Model

Conclusion

BF16, FP8, and NF4 each offer distinct trade-offs in image generation.
BF16 provides robust precision for high-quality results using 16 bits, FP8 boosts speed and efficiency for resource-constrained environments using 8 bits, and NF4 pushes the boundaries of optimization for cutting-edge applications by using just 4 bits per number.
The best choice depends on your project’s priorities—whether it’s output fidelity, computational speed, or memory efficiency.

Additional Notes

The original intent of this miniblog, in addition to example results provided side-by-side, was to also provide image generation times.
But while running timed generations, complexities related to the different representations used inside the CLIP and VAE models, and variable performance on different NVIDIA GPUs due to their internal architecture (after trying to focus on sampler iterations-per-second), led to significant variance in the results.
